Knuth Rotary Table RT 320 ( Part No. 125845) Setup table rotates on a large ring-shaped box way. Horizontal & Vertical Set up
Knuth Rotary Table RT 320
( Part No. 125845)
Highlights
-
Knuth RT 320 Rotary Table
- completely enclosed design, prevents contamination from dirt and chips
- Set up table rotates on a large ring-shaped box way
- the very effective clamp pulls the setup table down straight, without any change of position or radial pressure and presses it against the guideway
- for quick manual turning, the worm can be disengaged from the worm gear by pushing down the hand-lever
- setup table with 360° scale
- the zero-backlash of worm and worm gear is adjustable
- hand wheel scale gradation 10''
- hand wheel can be replaced with indexing plate
- with 6 radial setup T-slots
- very low profile
- guide slot in the vertical base plane
- can be used vertically or horizontally
Technical Details
Specifications - RT 320 - Rotary Table
| morse taper | MT 4 |
| ratio | 1:90 |
| setup (clamping) | horizontal or Vertical |
| measures and weights | |
| weight | 75 kg |
- Surface concentricity of work table setup surface 300 : 0.015
- concentricity of setup
- parallelism of setup to base surface 300 : 0.02
- concentricity of setup table taper bore
- parallelism of bore axis to vertical setup surface 0.03
- parallelism of bore axis to slot in the vertical setup surface 0.02
- parallelism between vertical setup surface and connecting axis taper center-tailstock center 0.02
- parallelism between slot in the vertical setup surface and the connecting axis between centers 0.02
- division accuracy 45"
Accessories / Tools - RT 320 - Rotary Table
| INDEX-feature / RT 160-320 125805 | |
| Tailstock / RT 320 125825 250 mm 3 jaw chuck for RT 320 |
Clients interested in any of the accessories for the RT 320 Rotary Table should contact us price and delivery details and full specification.
