Clarke Devil 7009 9 kw Industrial Electric Fan Heater ( 400v)

Highlights

A powerful fan heater for industrial applications including workshops, factories and garages.

• Electrically powered producing a dry heat without condensation or odour that may be present with similar gas powered heaters
• Features fan only plus high and low heat settings with adjustable thermostatic control
• Auto cooling and overheat protection
• Strong steel construction with stand for increased stability
• Supply: 400V/3ph - 16A
• This product is fitted with a 16A 3-phase 5-pin connector
• Requires DCL16A 16Amp socket and plug (code: 6925232)

Technical Details

Operating Voltage and Frequency: (V / Hz / Phs) 400 V / 50Hz / 3 Phase

Operating Temperature: (Min/Max) (°C): 0-40°C

Heat Output: (kW): 9 kW

Air Output: (m3/h) 474m3/h

Safety Device: Thermal cut-out

Duty Cycle Classification: Continuous duty

Electrical Insulation Class I

Product: Depth x Width x Height 442 x 406 x 562 mm

Product Weight 10.5 kg

Optional

Clarke 400v 3 Phase Mains Lead 2.8m with 16 Amp Plug & Socket ( DCL 16B)

Highlights

• 16 Amp
• Length 2.8m
• Three Phase
• 400Volt

Ideal application

Connecting extension lead for use with Devil 6005 (5kW), Devil 6009 (9kW), Devil 7005 (5kW) and Devil 7009 (9kW) electric fan heaters.

Please Note: A mains lead is not supplied with these heaters and has to be ordered seperately.

Can also be used in other 16 Amp load 3 Phase applications where an extension mains lead is required.

You will need a DCL 16B

Part No.. 6925233

Technical Details

Length	2.8 m
Amps	16
Socket Outlets	1
Cable Length	2.8 m
Volts	400 V
Max Current	16 Amp

Warranty

Clarke is a British based company whose products comply with British and European Standards and European safety and CE marking directives. Their products are supplied with a 1 year parts and labour warranty from date of purchase.
