Metal Lathe CL300M
This superb, precision mini lathe is
designed to perform a wide variety of tasks.
Solidly manufactured, the CL300M has a cast
iron bedway and many features usually found
on machines twice its size and price.
This machine can be used to turn mini precision
parts and in model making, using the power feed,
imperial screw cutting and includes a
four way tool post and compound mitre slide.
The lathe comes complete with a gear change kit
and the spanners and allen keys needed for setting
up and there are many optional extras available,
enabling you to up-grade your machine
to suit your individual needs.
300 watt, 230v 1ph electric motor with variable
speed control 100-2500rpm
Power feed operation with imperial screw cutting
left & right hand threads.
Includes compound mitre slide, 4 way tool post, self centering
3 jaw 80mm chuck, splashguard & undertray.
Spindle taper MT3 - Bore 20mm
Safety features include prominent emergency
stop button & chuck guard.
Dimensions (LWH) 820x295x300mm. Weight 40Kg
NB: OPTIONAL METRIC THREAD CUTTING CONVERSION KIT –
Imperial thread cutting indicator is fitted as standard to lead screw.
For Metric conversion order optional kit Part No.7610720
